Elite S 3/4" Automatic Shutoff Nozzle
Premium Conventional Pressure Sensitive Nozzle
The Elite S automatic shutoff nozzle is designed for retail and commercial fueling sites. The familiar styling brings comfort to the end user while the lightweight construction produces a smooth- working, rugged nozzle specifically designed for safety and endurance.
The Elite S Prepay pressure-sensitive nozzle has undergone extensive engineering upgrades specifically designed to deliver the most reliable functioning nozzle. The pressure- sensitive (no pressure, no flow) feature enables the station operator to control the dispensing of fuel. The Elite S features a user-friendly one-hand hold-open latch, and the standard safety attitude device feature provides automatic shut-off if raised above horizontal or if it falls from the vehicle.
Highlights
Specifications
Downloads
Highlights
Features
- Easy one-hand hold-open mechanism
- UL/ULC 2586 listed to be used in unleaded, auto diesel and Ethanol blends up to E10, E25, E85, and Bio Diesel blends up to B20
- Trickle Flo Poppet allows customers to easily regulate low-flow fuel dispensing
- Pressure sensitive design prevents spills in prepay fuel dispensing
- Updated separate cover and hand warmer design
- Integrated swivel options available on all Elite S models/Factory assembled swivels ensure the correct fit and reduces assembly time
- Attitude Device (AD) provides automatic shut-off if raised above horizontal or if it falls from the vehicle (safety feature standard on all Elite S models)
- All major oil company colors available
- Custom logo available upon request
- Splash shield included with each new nozzle
- Industry-leading 24-month warranty for all new Elite S nozzles
Specifications
Materials
- 3/4” Single body, sand cast aluminum
- Lever & handguard is Super-Tuff Glass Filled Nylon
- O-rings and Seals are Viton
- Unleaded Spout Assembly 13/16” OD
- Leaded Spout Assembly 15/16” OD
- Weight 2.2 lbs.
