Wayne Helix 4000 Fuel Dispenser
Wayne Helix 4000 Fuel Dispenser
The Helix 4000 dispenser is built with up to four nozzles and has the ability to dispense five fuel grades. Like the Helix 5000 dispenser, the Helix 4000 dispenser boasts centralized, flexible and upgradable payment options that enable fuel retailers to modify payment features as required, allowing their fuel business to grow and adapt to changes in the market.
Big Player, Small Profile
The Helix 4000 dispenser is built with four nozzles as standard, and has the ability to dispense two fuel grades, with the hose retraction option providing ample reach for easy refueling. As with all Helix dispensers, the 4000 model can be customized to showcase the best of your brand, with the H-style valance offering additional promotional space to really make an impact.
WAYNE IX PAYTM SECURE PAYMENT PLATFORM
The Wayne iX Pay secure payment platform incorporates the latest security standards to protect sensitive card holder data.
WAYNE TAPTM CONTACTLESS/NFC READER
The Wayne TAP near-field communication (NFC) reader enables mobile payment, such as Apple Pay and Android Pay, at the dispenser. The Wayne TAP reader hardware supports both magstripe and EMV® contactless protocols.
E25/B20 STANDARD
The Wayne Helix dispenser now comes with UL E25 listing as standard. This reflects Wayne’s ongoing intent of supplying retailers with the most flexible, reliable and future-proof equipment options. Regardless of what direction government regulations or next-generation vehicle technologies take, your investment will remain viable for years to come.
WAYNE SMART SECURE ACCESSTM
Wayne Smart Secure AccessTM secures your forecourt 24/7/365. It keeps your customers’ financial data safe by offering electronic protection against unauthorized access to the dispenser’s internal components, and comes with battery backup as standard, which means it keeps protecting your business and your customers even when the power is out.
WAYNE XFLOTM FUEL METER
While traditional piston meters are prone to drift over time, the Wayne Xflo MeterTM maintains its calibration, saving money by helping prevent fuel loss. The Xflo Meter also offers the industry’s only four-year re-calibration warranty, and it can achieve better flow rates than piston meters.
Available Grades: 2 (3-4 with blending)
Available Nozzles: 2 per side
Available Flow Rates: 40, 70 or 40-70 LPM
Hose Management: Hanging (standard), Retraction (optional)
Nozzle Reach: 4m (hanging), 4m (retraction)
Dispenser Orientation: Lane
Display Options: 6-7-5 LCD (standard)
Vapor Recovery: Yes (gasoline and ethanol)
Pump Type: CPU (Compact Pumping Unit) or remote
ARLA 32 Configurations: No
Customized Livery: Yes
Corrosion Resistance: At least C3, stainless steel doors available for harsh environments
Operating Temperature: -40°C to +55°C
Relative Humidity: Condensing
Dimensions: 1056mm (L) x 669mm (W) x 2368mm (H)
